Beskrivelse
The Holosun IRIS-4 is a compact, advanced quad-function aiming and illumination system engineered to meet the demands of modern professionals and enthusiasts alike. Precision-machined from 7075-T6 aluminum, the redesigned housing is 43% lighter, 29% lower, and 28% narrower than the legacy LS420, offering superior ergonomics without compromising structural integrity—ideal for integration on PDWs, SBRs, and standard rifle platforms.
At its core, the IRIS-4 combines a co-aligned visible green laser, infrared (IR) aiming laser, 60mW VCSEL-based IR illuminator, and a high-output white light delivering 1,000 lumens and 25,000 candela. This integration allows operators to transition seamlessly between daylight aiming, night vision engagements, and high-intensity white light use. The co-alignment of the lasers simplifies zeroing—users can calibrate both IR and VIS lasers simultaneously using the visible laser in daylight conditions, ensuring consistent point-of-aim across environments.
A key feature of the IRIS-4 is its top-mounted IR beam divergence slider, which enables on-the-fly adjustment of the IR illuminator's beam pattern from wide flood to tight spot—optimized for performance across a range of shooting needs. Dual independent fire buttons offer tactile, ambidextrous control of laser and light functions, while the updated rear-positioned power and mode selector provides streamlined controls.
The included three-button remote connects via a Crane plug and features a visible laser override for instant activation. For power flexibility, the IRIS-4 can be powered by two CR123A batteries (included), or one rechargeable 18650 battery (not included) —delivering reliable performance in any environment.
In the Box
- 1x IRIS-4
-
1x Triple Button Pressure Pad
Features
- IR Illuminator: 60mW VCSEL
- IR Laser: 0.7mW VCSEL
- Green / Red Laser: 5mW
- LED Light: 1,000 Lumens / 25,000 Candela
- Battery Type: 2x CR123A (included) / 18650 (not included)
- Weight: 8.5oz
Specifications
Physical
| Window Size | N/A |
| Dimension (in) | 4.2×2.3×1.4 |
| Weight (oz) | 8.5 |
Mechanical
| Housing Material | 7075 T6 Aluminum |
| Surface Finish | Hard Anodize |
| Adjustment per Click | 0.5 MOA |
| W&E Travel Range | ±50 MOA |
Environment
| Storage Temperature | -40℃~70℃ |
| Working Temperature | -30℃~60℃ |
| Submersion | IPX8 |
| Vibration | 1000G |
Illuminator
| White LED Candela | 25000 |
| Laser & Illuminator Type | Dual Laser & Dual Illuminator |
| White LED Output | 1000 Lumens |
| IR Illuminator Class | Class 1 |
| IR Illuminator Output | VCSEL 60mW |
| IR Pointer Class | Class 1 |
| IR Pointer Output | <0.7mw |
| Visible Laser Class | 3R |
| Visible Laser Output | <5mW |
